If you own a Ford truck or SUV, you might wonder about using Dodge wheels on your vehicle. Many people ask, “Will Dodge 5 lug wheels fit Ford?” In this article, we will explain everything you need to know. We will talk about wheel sizes, bolt patterns, and other important details. This will help you decide if you can use Dodge wheels on a Ford.
What Are 5 Lug Wheels?
First, let’s understand what 5 lug wheels mean. The word “lug” refers to the holes on a wheel. These holes fit over bolts on your car’s hub. A 5 lug wheel has five holes. These holes line up with five bolts on the car. This lets the wheel attach safely to the vehicle.
Many trucks and SUVs use 5 lug wheels. Both Dodge and Ford have many models with 5 lug wheels. But just because they both have five lugs does not mean the wheels will fit each other.
Why Do Wheels Need to Fit Exactly?
Wheels must fit the car perfectly. If they do not fit, the wheel can be unsafe. The wheel might wobble or come loose while driving. This can cause accidents or damage to the vehicle.
That is why it is important to know the exact size and shape of the wheel and the car’s hub. This includes the bolt pattern, center bore, and offset.
Understanding Bolt Patterns
The bolt pattern is the arrangement of the lug holes on the wheel. It is usually shown as two numbers. For example, 5×139.7. The first number means five lug holes. The second number means the diameter of the circle the holes make, in millimeters.
Dodge and Ford trucks often have different bolt patterns. For example:
| Brand | Common 5 Lug Bolt Pattern |
|---|---|
| Dodge | 5×139.7 (5×5.5 inches) |
| Ford | 5×135 or 5×139.7 depending on model |
Ford trucks sometimes use 5×135 or 5×139.7 bolt patterns. Dodge mostly uses 5×139.7 for trucks like the Ram. This means some Dodge wheels can fit Ford trucks if the bolt pattern is the same.
Center Bore Size
The center bore is the hole in the middle of the wheel. It fits over the hub on the car. This helps center the wheel on the axle. If the center bore is too small, the wheel will not fit. If it is too big, the wheel will not be centered properly.
Dodge and Ford sometimes have different center bore sizes. For example:
- Dodge center bore: about 87.1 mm
- Ford center bore: about 106.1 mm or 110 mm
If the center bore of the Dodge wheel is smaller, it will not fit on a Ford hub. But if it is bigger, you can use hub centric rings. These rings fill the gap and center the wheel.
Credit: www.f150forum.com
Wheel Offset and Backspacing
Offset is the distance between the wheel’s mounting surface and its centerline. It affects how far the wheel sticks out or sits inside the wheel well. Backspacing is the distance from the mounting surface to the back edge of the wheel.
Using wheels with a wrong offset can cause problems. The wheel might rub against brakes, suspension, or fenders. It can also change the way your truck handles.
Dodge and Ford wheels often have different offsets. You should compare the offset before swapping wheels. A small difference might be okay. A big difference could cause issues.
Will Dodge 5 Lug Wheels Fit Ford?
Now the main question. Will Dodge 5 lug wheels fit Ford? The answer is: it depends on your vehicle and the wheels.
If your Ford truck has a 5×139.7 bolt pattern, and the Dodge wheels also have 5×139.7, the wheels can fit. But you must also check the center bore and offset.
If the center bore is smaller on the Dodge wheel, you cannot fit it directly. You will need hub centric rings. These rings help center the wheel on the Ford hub.
If the offset is very different, you might face rubbing or handling problems. So, you should measure the offset on both wheels.
For Ford models with 5×135 bolt patterns, most Dodge wheels will not fit. You need wheels with the exact bolt pattern.
How to Check If Wheels Will Fit
Here are steps to check wheel fitment:
- Find your Ford’s bolt pattern. Use the owner’s manual or online sources.
- Find the bolt pattern of the Dodge wheels you want to use.
- Compare center bore sizes of both wheels and vehicle hubs.
- Check the offset of both wheels.
- If needed, buy hub centric rings to fill gaps.
- Make sure the wheel size matches your Ford’s tire size.
Why Do People Want to Use Dodge Wheels on Ford?
Some people like the look of Dodge wheels. Others want to save money by using wheels they already have. Some wheels are stronger or lighter. So, swapping wheels can make sense.
But always remember safety comes first. Using wheels that do not fit can be dangerous. It can also cause damage to your Ford truck.
Summary Table: Dodge vs Ford 5 Lug Wheels
| Feature | Dodge 5 Lug Wheels | Ford 5 Lug Wheels |
|---|---|---|
| Bolt Pattern | Mostly 5×139.7 | 5×135 or 5×139.7 |
| Center Bore | About 87.1 mm | About 106.1 or 110 mm |
| Offset | Varies by model | Varies by model |
| Fit Without Modifications | Fits Ford 5×139.7 bolt pattern with hub rings | Fits Dodge wheels with 5×139.7 bolt pattern |
Final Thoughts
Can you put Dodge 5 lug wheels on a Ford? Sometimes yes. It depends on bolt pattern, center bore, and offset.
Always check your Ford’s specs. Compare them with the Dodge wheels you want. Use hub centric rings if the center bore is bigger on the Ford.
If you are not sure, ask a wheel expert or mechanic. They can help you find the right wheels for your Ford.
Using wheels that fit well keeps you safe. It also makes your truck look good and drive well.
